VitalMRO is Authorized Distributor for This Product.
| Operating pressure [bar] | 2.5 to 16 |
| Coil characteristic value | 24 V DC: 3 W |
| Permitted voltage oscillations | ± 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Material information | RoHs compliant |
| Maritime classification | see Certificate |
| Air purity class at the output | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| electrical connection: | Wiring diagram Form C acc. to EN 175301-803 acc. to DIN EN 175301-803 Plug |
| Construction set up | Piston pusher |
| Actuation type | Electrical |
| Sealing principle | Soft |
| Exhaust function | Cannot be throttled |
| Hand assist actuation | Ratcheting |
| Reset mode | Mechanical spring |
| Control type | pilot operated |
| Valve function | 3/2 closed monostable |
| Power-on time | 100% |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| Fastening type | pipe installation With Accessories |
| installation position | arbitrary |
| Flow direction | Not reversible |
| Product weight [g] | 500 |
| Pneumatic connection 3 | G1/4 |
| Signal condition display | With Accessories |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Weight | 500 g / Pcs |
