VitalMRO is Authorized Distributor for This Product.
| Stroke [mm] | 10 |
| Piston diameter | 6 mm |
| Operating mode actuator unit | Joch |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Guide | Ball cage guide |
| Construction set up | Joch kinematics |
| Position detection | without |
| Operating pressure [bar] | 1 to 6 |
| Repeatability | 0.2 mm |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | 10 to 50 |
| Max. force Fy [N] | 20 |
| Max. force Fz [N] | 20 |
| Max. torque Mx [Nm] | 0,3 |
| Max. torque My [Nm] | 0,4 |
| Max. torque Mz [Nm] | 0,4 |
| Theoretical force at 6 bar, Return flow [N] | 12,7 |
| Theoretical force at 6 bar, flow [N] | 17 |
| Moving mass [g] | 17 |
| Product weight [g] | 52 |
| Fastening type | With Female thread and dowel pin |
| Pneumatic connection | M3 |
| Material information | Copper and PTFE-free RoHs compliant |
| Seals material | NBR |
| Housing material | High-alloyed stainless steels |
| Piston rod material | High-alloyed stainless steels |
| Weight | 52 g / Pcs |
| GTIN | 4052568216443 |
| Customs duty number | 84123100 |
| RoHS compliant | Yes |
| Manufacturer | Festo |
