VitalMRO is Authorized Distributor for This Product.
| size | Standard |
| Nominal width [mm] | 6,0 |
| Seal type on stud | coating |
| installation position | arbitrary |
| Packing size | 10 |
| Construction set up | Push-pull principle |
| Operating pressure complete temperature range [bar] | -0.95 to 6 |
| Temperature depending operating pressure [bar] | -0.95 to 14 |
| Maritime classification | see Certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] Water according to manufacturer declaration at www.festo.com |
| Information about operating and control medium | Oiled operation possible |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -10 to 80 |
| Product weight [g] | 14,0 |
| Pneumatic connection 1 | Male thread R1/8 |
| Pneumatic connection 2 | For hose exterior diameter 8 mm |
| Sleeve colour | blue |
| Material information | RoHs compliant |
| Housing material | brass nickel-plated |
| Sleeve material | POM |
| Tube seal, hose seal material | NBR |
| Hose clamping segment material | High-alloyed stainless steels |
