| Exterior diameter [mm] | 12 |
| Flow relevant bending radius [mm] | 62 |
| Inside diameter [mm] | 8,0 |
| Min. bend radius [mm] | 33 |
| Hose properties | compatible with cable carriers for applications with high cycle rate |
| Hose test conditions | Compatibility with cable carriers: >5 million cycles acc. to FN 942021 |
| Temperature depending operating pressure [bar] | -0.95 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] Water according to manufacturer declaration at www.festo.com |
| ambient temperature [°C] | -35 to 60 |
| Product weight to length [Kilogramm ] | 0,0729 |
| Pneumatic connection | for push-in fitting exterior diameter 12 mm |
| colour | blue |
| Shore hardness | D 52 ±3 |
| Material information | Copper and PTFE-free RoHs compliant |
| Hose material | TPE-U(PU) |
| Food compatibility | See expanded material information |
| Permission | TÜV |
| Weight | 0,0729 Kilogramm / m |
